Carbon Steel Robot Grinding Machine , Metal Surface Buffing And Polishing Machine

Large Image : Carbon Steel Robot Grinding Machine , Metal Surface Buffing And Polishing Machine

Product Details:

Place of Origin:	China(Mainland)
Brand Name:	DZ
Certification:	CE
Model Number:	Robot

Payment & Shipping Terms:

Minimum Order Quantity:	1set
Price:	Negotiable
Packaging Details:	Plastic film packaging and put in plywood wooden cases or according to customer's requirements.
Delivery Time:	2weeks
Payment Terms:	L/C, T/T, Western Union
Supply Ability:	30sets/per month

Contact Now

Detailed Product Description

Material:	Carbon Steel	Brand Of Robot:	FUNAC
Condition:	New	After-sales Service:	Engineers Available To Service Machinery Overseas
Application:	Bathroom Industry,Hardware Industry,Tool Industry,Furniture Industry	Voltage:	380V

Industrial Stainless Steel Casting Pipe Fittings Metal Surface Grinding And Polishing Machine Automatic Polishing

Quality Assurance

Quality is always our top priority. We are familiar with the international standards & regulations. All our designs comply, meet or even exceed ISO9001:2008 standards. We use top grade components and we perform extensive testing to make sure our equipment's quality completely satisfy our customers.

TECHNICAL PARAMETERS
To fulfill the different product weight and sizere quirement,different requirements for belt sander of customers,we have 4 models for customer options.
	20GA Specifications	20GBSpecifications	35GSpecifications	50GSpecifications
Robot Cell	FUNAC	FUNAC	FUNAC	FUNAC
Robot Model	20iA/20	20iA/20	20iA/35	20iA/50
Rated Voltage	380V	380V	380V	380V
Machine Power	7.6KW	10.5KW	11KW	16KW
Sand Belt Machine Quantity	1	2	2	2
Sand Belt Quantity	4	4	4	4
Sand Belt Dimensions	3000mm×4	3000mm×4	4000mm×4	4000mm×4
Feed Table	1	1	1	1

The equipment consisting of main components:Sand Belt Machine ,Feed Table,Sand belt machine control system,manipulator,fixture ,automatic feed tray and contact wheeland etc.

NO.	QUANTITY	DESCRIPTION
1	2	Sand Belt Machine 1.1The working wheel is equipped with denim buren standard, which can realize a variety of sand belt hanging method, and meet the requirements of different product grinding process 1.2 The mould function in the middle ensures the polishing of complex products 1.3 Sand belt wear control system, improve machining stability and sand belt life 1.4 sand belt break detection function, automatic identification of sand belt working state 1.5Foam bar mechanism or soap mechanism, reduce fine abrasive belt sticky sand, heat and other problems
2	1	Feed Table 2.1 The feeding table is set with double working positions, high positioning accuracy and flexible floating working energy 2.2 After the processing is completed, the machine will quit automatically and prompt the operator to change the product. 2.3 Each station can hold 10-20 pieces of products
